CNC DOOR LOCK M5.2-1228-AR
- CLICK HERE TO DOWNLOAD PDF FILE
- Max feeding speed: 50m/min
- Max working speed: 20m/min
- Max processing length: 2800mm
- Max processing thickness: 80mm
- Max processing width: 1220mm
- Type of transmission: X, Y axis with German Rotalin grinding rack precision rack Taiwan Lapping guide square rail(Y axis 30, X axis 25)Z-axis with Taiwan grinding TBI precision ball screw.
- Table structure: Two Schmitz strip tables, single strip table with 14 Schmitz adsorption blocks, five Schmitz positioning cylinders
- Horizontal spindle motor: 7.5KW high power manual tool changer 18000-24000 rpm/min
- Vertical spindle motor with Italian Hiteco angle head: 9KW CC Air-cooled automatic tool changer 0-24000 rpm/min.
- Four milling heads composite head: High-precision machining unit with built-in imported bearings and gears
- Tools magazine: Three follow-up straight tools magazine
- Drive system: Taiwan DELTA servo.
- Reducer: Japan SHIMPO
- Control system: Taiwan DELTA
- Command code: G code.
- Lubrication system: Automatic Lubrication system
- Component: France Schneider
- Inverter: Hpmont
- Power, voltage, pressure: 30KW、3P AC 380V/50HZ 、≧6.5Kgf/cm²
- Single machine Weight: 3.5 ton
- Single machine overall dimension: Length*Width*height:3700x2650x2400(mm)
- View More:
- https://youtu.be/el933aiesOw
